◎◎事件

  ●單一節點的程式 *.gd

  宣告：signal 事件子
  呼叫：emit_signal("事件子")

  ●使用方

 若是透過 UI 介面的實體化，
 "事件子"會出現在被實體化的那個節點的事件上，
 再用 connect 與程式碼連結。

 若是用程式碼來宣告實體化，
 則開頭要先 export (PackedScene) var 場景甲，
 並在使用方節點的 Inspector 把 *.tscn 從資料夾拖曳到變數 場景甲 上面
 事件會以 func _on_場景甲_事件子() 出現在使用方節點的程式裡

◎◎變數

  export (int) var 變數名稱丙

  用export的變數，會出現在 Inspector/ScriptVariables裡面，可在UI介面中設定數值

Project/Project Settings...
 Display/Window/Size/Width→480, Height→720
 Display/Window/Stretch/Mode→2d, Aspect→keep
 Rendering/2D/Snapping/Use GPU Pixel Snap→勾選On

------ 玩家

(Add/Create a New Node)→Area2D→Create,改名Player_area2d
Scene/Save Scene→Player_area2d.tscn→Save
(以後只要遇到有 Select Node 字眼，就是先點選其他空白處，再點選回來)
Select Node Player_area2d, click [Make sure the object's children are not selectable.]

Select Node Player_area2d, (Add/Create a New Node)→AnimatedSprite→Create
Select Node AnimatedSprite, Inspector/AnimatedSprite/Frames/New SpriteFrames
Select Node AnimatedSprite, 下方 Animations/New Animation 兩次
將三個 animation 分別改名為 run, idle, hurt
點選 run,從左方 FileSystem 把對應的 *.png 拖曳到右邊 Animation Frames 的方框中，修改 Animations/Speed 為 8 FPS。
點選 idle,從左方 FileSystem 把對應的 *.png 拖曳到右邊 Animation Frames 的方框中，修改 Animations/Speed 為 8 FPS。
點選 hurt,從左方 FileSystem 把對應的 *.png 拖曳到右邊 Animation Frames 的方框中，修改 Animations/Speed 為 8 FPS。
Select Node AnimatedSprite, Inspector/AnimatedSprite/Offset→x=0, y=-5 (為了置中而調整)

Select Node Player_area2d, (Add/Create a New Node)→CollisionShape2D→Create
Inspector/CollisionShape2D/Shape→New RectangleShape2D
Workspace/2D/Viewport/調整框框，包住 Player_area2d

Select Node Player_area2d, Scene/綠色加號(Attach a new or existing script to the selected node)→Player_area2d.gd→Create
●Begin-Player_area2d.gd
extends Area2D

export (int) var speed
var velocity = Vector2()
var screensize = Vector2(480, 720)
●End-Player_area2d.gd

Select Node Player_area2d, Inspector→Player_area2d/Script Variables/Speed→350

Select Node Player_area2d, Workspace/Script 增加一鍵盤處理的函數
●Begin-Player_area2d.gd
func get_input():
	velocity = Vector2()
	if Input.is_action_pressed("ui_left"):
		velocity.x -= 1
	if Input.is_action_pressed("ui_right"):
		velocity.x += 1
	if Input.is_action_pressed("ui_up"):
		velocity.y -= 1
	if Input.is_action_pressed("ui_down"):
		velocity.x += 1
	if velocity.length() > 0:
		velocity = velocity.normalized() * speed
●End-Player_area2d.gd

增加一標準處理的函數
●Begin-Player_area2d.gd
func _process(delta):
	get_input()

	position += velocity * delta
	position.x = clamp(position.x, 0, screensize.x)
	position.y = clamp(position.y, 0, screensize.y)

    # 可透過錢字號來操控子節點
	if velocity.length() > 0:
		$AnimatedSprite.animation = "run"
		$AnimatedSprite.flip_h = velocity.x < 0
	else:
		$AnimatedSprite.animation = "idle"

●End-Player_area2d.gd

增加開始與結束函數
●Begin-Player_area2d.gd
func start(pos):
	set_process(true) # 使本節點可以運作
	position = pos
	$AnimatedSprite.animation = "idle"

func die():
	$AnimatedSprite.animation = "hurt"
	set_process(false) # 使本節點停止運作
●End-Player_area2d.gd

宣告事件名稱
●Begin-Player_area2d.gd
# 下兩行請放在 extends Area2D 之後
signal sig_pickup
signal sig_hurt
●End-Player_area2d.gd

Select Node Player_area2d, 右邊 Node/Signals/Area2D/area_entered(area: Area2D), 按右鍵, Connect..., Connect
●Begin-Player_area2d.gd
func _on_Player_area2d_area_entered(area):
	if area.is_in_group("grp_coins"):
		area.pickup()
		emit_signal("sig_pickup")
	if area.is_in_group("grp_obstacles"):
		emit_signal("sig_hurt")
		die()
●End-Player_area2d.gd

------ 錢幣

Scene/New Scene
(Add/Create a New Node)→Area2D→Create,改名Coin_area2d

Scene/Save Scene→Coin_area2d.tscn→Save
Select Node Coin_area2d, (Add/Create a New Node)→AnimatedSprite→Create
Select Node Coin_area2d, (Add/Create a New Node)→CollisionShape2D→Create

Select Node AnimatedSprite, Inspector/AnimatedSprite/Frames/New SpriteFrames
Select Node AnimatedSprite, 下方 Animations
點選 default,從左方 FileSystem 把對應的 *.png 拖曳到右邊 Animation Frames 的方框中，修改 Animations/Speed 為 12 FPS。
Inspector/AnimatedSprite/Node2D/Transform/Scale→x=0.5, y=0.5

Select Node CollisionShape2D
Inspector/CollisionShape2D/Shape→New RectangleShape2D
Workspace/2D/Viewport/調整框框，包住 Coin_area2d

Select Node Coin_area2d, 右邊 Node/Groups，填入 grp_coins，按下 Add

Select Node Coin_area2d, Scene/綠色加號(Attach a new or existing script to the selected node)→Coin_area2d.gd→Create
●Begin-Coin_area2d.gd
extends Area2D

var screensize = Vector2()

func pickup():
	queue_free() # 移除自己這個節點
●End-Coin_area2d.gd

------ 主場景

Scene/New Scene
(Add/Create a New Node)→Node→Create,改名Main_node

Scene/Save Scene→Main_node.tscn→Save
Select Node Main_node, Scene/綠色加號(Attach a new or existing script to the selected node)→Main_node.gd→Create

Select Node Main_node, (Add/Create a New Node)→TextureRect→Create。重新命名為 tr_Background
Select Node Main_node, (鎖鏈形狀)Instance Child Scene→選取  Player_area2d.tscn→Open
Select Node Main_node, (Add/Create a New Node)→Node→Create。重新命名為 node_CoinContainer
Select Node Main_node, (Add/Create a New Node)→Position2D→Create。重新命名為 p2d_PlayerStart
Select Node Main_node, (Add/Create a New Node)→Timer→Create。重新命名為 tmr_GameTimer

Select Node tr_Background, 把 grass.png 從 (左下角)FileSystem 拖曳到 (右上角)Inspector/tr_Background/TextureRect/Texture 的右邊格子
Inspector/tr_Background/TextureRect/Stretch Mode→Tile
Workspace/2D/Viewport/Layout→Full Rect

Select Node p2d_PlayerStart, Inspector/p2d_PlayerStart/Node2D/Transform/Position→x=240, y=350

Select Node Main_node, Workspace/Script
●Begin-Main_node.gd
extends Node

export (PackedScene) var Coin_area2d # 只有宣告外部場景，還須到Inspector指定才行
export (int) var playtime

var level
var score
var time_left
var screensize
var playing = false
●End-Main_node.gd

Select Node Main_node,
從 FileSystem 把 Coin_area2d.tscn 拖曳到 Inspector/Main_node/Script Variables/Coin Area 2d 的右邊格子 # 裡面有宣告，外面有指定
Inspector/Main_node/Script Variables/Playtime→30 #(30秒是原本遊戲預設的時間)

Select Node Main_node, Workspace/Script
●Begin-Main_node.gd
func _ready():
	randomize()
	screensize = get_viewport().get_visible_rect().size
	$Player_area2d.screensize = screensize
	$Player_area2d.hide()

func new_game():
	playing = true
	level = 1
	score = 0
	time_left = playtime
	$Player_area2d.start($p2d_PlayerStart.position) # 此start函數是自訂函數
	$Player_area2d.show()
	$tmr_GameTimer.start() # 此start函數是內建函數
	spawn_coins()

func spawn_coins():
	for i in range(4 + level):
		var c = Coin_area2d.instance() # 進行實體化
		$node_CoinContainer.add_child(c)
		c.screensize = screensize
		c.position = Vector2(rand_range(0, screensize.x), rand_range(0, screensize.y))
●End-Main_node.gd

為了測試，現在可以先把 new_game() 加到 _ready() 裡面最後一行

Project/Project Settings.../General/Application/Run/Main Scene→選取 Main_node.tscn→Close

Select Node Main_node, Workspace/Script
●Begin-Main_node.gd
func _process(delta):
	if playing and $node_CoinContainer.get_child_count() == 0:
		level += 1
		time_left += 5
		spawn_coins()
●End-Main_node.gd

------ 抬頭顯示器

Scene/New Scene
(Add/Create a New Node)→CanvasLayer→Create,改名HUD_cl

Select Node HUD_cl, (Add/Create a New Node)→Label→Create。重新命名為 MessageLabel
Select Node MessageLabel, Workspace/2D/Viewport/Layout→HCenter Wide
Inspector/MessageLabel/Label/Text→"Coin Dash!", Align→Center, V Align→Center
Inspector/MessageLabel/Control/Theme Overrides/Fonts/勾選 Font, 選取 New DynamicFont
Inspector/MessageLabel/Control/Theme Overrides/Fonts/點開 DynamicFont/Font/Font Data 右邊的格子，請從 FileSystem 拖曳字型(.ttf)到這裡
Inspector/MessageLabel/Control/Theme Overrides/Fonts/點開 DynamicFont/Settings/Size→48

Scene/Save Scene→HUD_cl.tscn→Save

Select Node HUD_cl, (Add/Create a New Node)→MarginContainer→Create。
Workspace/2D/Viewport/Layout→Top Wide
Inspector/MarginContainer/Control/Margin/Left→10, Top→10, Right→10

Select Node MessageLabel, Ctrl+D(複製) 兩次
將 MessageLabel2, MessageLabel3 拖曳到 MarginContainer 上方，放開

Scene/MessageLabel2 改名為 ml_ScoreLabel, MessageLabel3 改名為 ml_TimeLabel

Select Node ml_ScoreLabel
Inspector/ml_ScoreLabel/Label/Text→0, Align→Left

Select Node ml_TimeLabel
Inspector/ml_TimeLabel/Label/Text→0, Align→Right

Select Node HUD_cl, Scene/綠色加號(Attach a new or existing script to the selected node)→HUD_cl.gd→Create

●Begin-HUD_cl.gd
extends CanvasLayer

signal sig_start_game

func _ready():
	pass

func update_score(value):
	$MarginContainer/ml_ScoreLabel.text = str(value)

func update_timer(value):
	$MarginContainer/ml_TimeLabel.text = str(value)
●End-HUD_cl.gd

Select Node HUD_cl, (Add/Create a New Node)→Timer→Create。重新命名為 MessageTimer

Inspector/MessageTimer/Timer/Wait Time→2, One Shot→勾選On

Select Node HUD_cl, Workspace/Script
●Begin-HUD_cl.gd
func show_message(text):
	$MessageLabel.text = text
	$MessageLabel.show()
	$MessageTimer.start()
●End-HUD_cl.gd

Select Node MessageTimer, Node/Signals/Timer/timeout()→按右鍵 Connect...→Connect
●Begin-HUD_cl.gd
func _on_MessageTimer_timeout():
	$MessageLabel.hide()
●End-HUD_cl.gd

Select Node HUD_cl, (Add/Create a New Node)→Button→Create。重新命名為 StartButton

Select Node StartButton,
Inspector/StartButton/Button/Text→Start
Inspector/StartButton/Control/Margin/Top→-150, Bottom→-50
Inspector/StartButton/Control/Theme Overrides/Fonts/勾選 Font, 右邊格子選 New DynamicFont，點選 DynamicFont
 Settings/Size→48
 Font/Font Data，右邊格子，把 *.ttf 拖曳過來
Select Node StartButton, Workspace/2D/Layout→Center Bottom

Select Node StartButton, Node/Signals/BaseButton/pressed() 按右鍵 Connect...→Connect

●Begin-HUD_cl.gd
func _on_StartButton_pressed():
	$StartButton.hide()
	$MessageLabel.hide()
	emit_signal("sig_start_game")

func show_game_over():
	show_message("Game Over")
	yield($MessageTimer, "timeout") # 暫停執行，等待事件被觸發
	$StartButton.show()
	$MessageLabel.text = "Coin Dash!"
	$MessageLabel.show()
●End-HUD_cl.gd

------ 重回主場景

在 FileSystem 把 Main_node.tscn 點兩下

Scene, Select Node Main_node, (Instance Child Secne)→選取 HUD_cl.tscn→Open

Select Node tmr_GameTimer, Node/Signals/Timer/timeout() 上面按右鍵，Connect ...→Connect

●Begin-Main_node.gd
func game_over():
	playing = false
	$tmr_GameTimer.stop()
	for coin in $node_CoinContainer.get_children():
		coin.queue_free()
	$HUD_cl.show_game_over()
	$Player_area2d.die()

func _on_tmr_GameTimer_timeout():
	time_left -= 1
	$HUD_cl.update_timer(time_left)
	if time_left <= 0:
		game_over()

func _on_Player_area2d_sig_pickup(): # 注意，這個函式也要從 Node 那邊 connect 喔
	score += 1
	$HUD_cl.update_score(score)

func _on_Player_area2d_sig_hurt(): # 注意，這個函式也要從 Node 那邊 connect 喔
	game_over()
●End-Main_node.gd

Select Node HUD_cl, Node/Signals/HUD_cl.gd/sig_start_game() 上面按右鍵 Connect ...，在 Receiver Method 填入 new_game→Connect

到 _ready() 函數中，把 最後一行的 new_game() 刪除掉
來到 new_game() 函數中，在最後面，加入下面兩行

$HUD_cl.update_score(score)
$HUD_cl.update_timer(time_left)

------ 更進一步

Select Node Coin_area2d, (Add/Create a New Node)→Tween→Create

Select Node Coin_area2d, Workspace/Script

●Begin-Coin_area2d.gd
func _ready():
	$Tween.interpolate_property($AnimatedSprite, 'scale', $AnimatedSprite.scale, $AnimatedSprite.scale * 3, 0.3, Tween.TRANS_QUAD, Tween.EASE_IN_OUT)

func pickup():
	monitoring = false # 避免動畫途中，又有新事件觸發
	$Tween.start()
    # 原本的 queue_free() 就刪除囉。
●End-Coin_area2d.gd

Select Node Tween, Node/Signals/Tween/tween_all_completed 上面按右鍵 Connect...→Connect

●Begin-Coin_area2d.gd
func _on_Tween_tween_all_completed():
	queue_free()
●End-Coin_area2d.gd

回頭修改效果

●Begin-Coin_area2d.gd
func _ready():
	$Tween.interpolate_property($AnimatedSprite, 'scale', $AnimatedSprite.scale, $AnimatedSprite.scale * 3, 0.3, Tween.TRANS_QUAD, Tween.EASE_IN_OUT)
	$Tween.interpolate_property($AnimatedSprite, 'modulate', Color(1,1,1,1), Color(1,1,1,0), 0.3, Tween.TRANS_QUAD, Tween.EASE_IN_OUT)
●End-Coin_area2d.gd

------ 更進一步，增加聲音

Select Node Main_node, (Add/Create a New Node)→AudioStreamPlayer→Create，重新命名為 asp_CoinSound
Select Node Main_node, (Add/Create a New Node)→AudioStreamPlayer→Create，重新命名為 asp_LevelSound
Select Node Main_node, (Add/Create a New Node)→AudioStreamPlayer→Create，重新命名為 asp_EndSound

上面三個 audiostreamplayer，依次從FileSystem那裡拖曳對應的聲音檔到 Inspector/asp_...Sound/AudioStreamPlayer/Stream 右邊的格子裡

Select Node Main_node, Workspace/Script
在 _on_Player_area2d_sig_pickup() 的最後面加入 $asp_CoinSound.play()
在 game_over() 的最後面加入 $asp_EndSound.play()
在 spawn_coins() 的最後面加入 $asp_LevelSound.play()

------ 更進一步，紅利措施

在 FileSystem 雙擊 Coin_area2d.tscn
Scene/Save Scene As→Powerup_area2d.tscn→Save

把 Scene 裡根節點的名字從 Coin_area2d 改成 Powerup_area2d
Select Node Powerup_area2d，點擊 Scene/紅色叉叉 (刪除script)
Select Node Powerup_area2d，確認 Node/Signals/Area2D/area_entered 已經 disconnect
Select Node Powerup_area2d，Node/Groups，新增 grp_powerups，刪除 grp_coins

Select Node AnimatedSprite, 在 Animations/Animation Frames 裡面，刪除全部圖檔，拖曳正確的圖檔進來

在 FileSystem 雙擊 Powerup_area2d.tscn
Scene/綠色加號(Attach a new or existing script to the selected node)→Powerup_area2d.gd→Create

在 FileSystem 雙擊 Coin_area2d.gd, Workspace/Script, 複製所有程式碼

在 FileSystem 雙擊 Powerup_area2d.tscn, Select Node Powerup_area2d, Workspace/Script, 貼上程式碼, 存檔

Select Node Powerup_area2d, (Add/Create a New Node)→Timer→Create, 重新命名為 tmr_Lifetime
Inspector/tmr_Lifetime/Timer/Wait Time→6, One Shot→勾選On, Autostart→勾選On

Select Node tmr_Lifetime, Node/Signals/Timer/timeout() 上面按右鍵，Connect...→Connect

●Begin-Powerup_area2d.gd
func _on_tmr_Lifetime_timeout():
	queue_free()
●End-Powerup_area2d.gd

在 FileSystem 雙擊 Main_node, Scene/Select Node Main_node, (Add/Create a New Node)→Timer→Create, 重新命名為 tmr_PowerupTimer
Inspector/tmr_PowerupTimer/Timer/One Shot→勾選On

Select Node Main_node, (Add/Create a New Node)→AudioStreamPlayer→Create, 重新命名為 asp_Powerup
Inspector/asp_Powerup/AudioStreamPlayer/Stream, 把對應的音檔拖曳到右邊的格子內

Select Node tmr_PowerupTimer, Node/Signals/Timer/timeout 在上面按右鍵 Connect...→Connect

●Begin-Main_node.gd
# 下面一行，請插到最上方，另一個 export (PackedScene) ...... 的下面一行
export (PackedScene) var Powerup_area2d # 只有宣告外部場景，還須到Inspector指定才行

Select Node Main_node, Inspector/Main_node/Script Variables/Powerup Area 2d 右邊的格子，
請把 Powerup_area2d.tscn 從 FileSystem 拖曳到這裡

# 下面的函數，可以放到最後面
func _on_tmr_PowerupTimer_timeout():
	var p = Powerup_area2d.instance()
	add_child(p)
	p.screensize = screensize
	p.position = Vector2(rand_range(0, screensize.x), rand_range(0, screensize.y))
●End-Main_node.gd

Select Node Main_node, Workspace/Script, 找到 func _process(delta) 在最後面與 spawn_coins() 相同層次
新增兩行程式碼
$tmr_PowerupTimer.wait_time = rand_range(2,5)
$tmr_PowerupTimer.start()

雙擊 Player_area2d.tscn, Workspace/Script, 找到 _on_Player_area2d_area_entered 函數，並改成如下程式碼

●Begin-Player_area2d.gd
func _on_Player_area2d_area_entered(area):
	if area.is_in_group("grp_coins"):
		area.pickup()
		emit_signal("sig_pickup", "coin")
	if area.is_in_group("grp_powerups"):
		area.pickup()
		emit_signal("sig_pickup", "powerup")
	if area.is_in_group("grp_obstacles"):
		emit_signal("sig_hurt")
		die()
●End-Player_area2d.gd

雙擊 Main_node.tscn, Workspace/Script, 將 _on_Player_area2d_sig_pickup 修改成如下樣子

●Begin-Main_node.gd
func _on_Player_area2d_sig_pickup(type):
	match type:
		"coin":
			score += 1
			$HUD_cl.update_score(score)
			$asp_CoinSound.play()
		"powerup":
			time_left += 5
			$asp_Powerup.play()
			$HUD_cl.update_timer(time_left)
●End-Main_node.gd

雙擊 Coin_area2d.tscn
Select Node AnimatedSprite, Animations/default, Loop 取消

Select Node Coin_area2d, (Add/Create a New Node)→Timer→Create
把下兩行加到 _ready 後面
$Timer.wait_time = rand_range(3, 8)
$Timer.start()

Select Node Timer, Node/Signals/Timer/timeout() 上面按右鍵，Connect...→Connect

●Begin-Coin_area2d.gd
func _on_Timer_timeout():
	$AnimatedSprite.frame = 0
	$AnimatedSprite.play()
●End-Coin_area2d.gd
